Everything you must know about diode lasers.
Differences between Endurance lasers
2.1 -> 3.5 watt -> 5.6. watt – 8 -> 8.5 watt. More power & more cutting and engraving abilities
10 watt “Invincible” -> 10 watt Delux : has an air nozzle, bigger focusing ring, laser box instead of a laser control board.
10 watt Delux -> 10 watt Plus : has a TEC cooling with an external heatsink, air compressor.
8.5 watt -> 8.5 watt PRO : has a metal laser box ver 2.0 with MO2 and a smaller heatsink. (Additional accessories in the package)
10 watt “Invincible” -> 10 watt PRO: has a metal laser box ver 2.0 with MO2 and polished shining aluminum housing. (Additional accessories in the package)
10 watt Plus -> 10 watt PRO PLUS : has a metal laser box ver 2.0 with MO2, a ver 2.0 air nozzle, double TEC cooling with a turbine fan. (Additional accessories in the package)
When you order from Endurance lasers you get all you need in the package!
Fast and secure checkout on Endurance online store >>>
All you need to know about Endurance best seller modules in one video
Endurance makes and delivers solid-state (DPSS) lasers with different power output
and diode lasers starting from 2 watt (200 mw) up to 30 watt (30000 mw).
Endurance lasers have class 4 and you must comply with safety rules: always wear goggles and never ever aim at any living being.
Endurance lasers are reliable, have rated power output, and can work continuously for 48-72 hours.
All lasers are assembled and tested individually.
The technological structure of the Endurance lasers
The heart of the Endurance lasers (10 watt models) is NICHIA 445nm powerful diodes in TO5 housing.
The diodes are securely fixed (collimated) in copper or aluminum housings.
Either 3 elements (long focal) or G-2 (short focal) lenses can be added to the housings by way of screwing on.
All Endurance lenses have labels marking the best focus achieved.
Endurance makes its own heatsinks with aluminum housings.
To spread up the generated heat we use a high-quality thermal conductive paste.
The laser diode requires stabilized current and very accurate voltage settings.
Endurance makes its own laser controller board with a Zener diode at the end of the board.
The laser controller board has a TTL (PWM) that works from 3.5V-24V range wire and a DC/DC converter that allows a laser unit to operate in the range of 9-16V. All Endurance PRO versions have analog input 0-10V.
The TTL allows changing the power (intensity) during the process of laser cutting/laser engraving.
We have developed an Endurance MO1 PCB and Mo2 PCB enabling to use of an external power supply to feed the laser when the mainboard does not have enough power. In this case, just add an Endurance MO1 PCB and get an external power source for the laser.
Learn more about our laser components >>>
About Endurance MO1 PCB. The driver board to run the laser from external power supply.
Learn more about useful accessories
Key Technological Advantages of Endurance Lasers
- An effective current stabilizing schematics preventing the diode from over-clocking.
- A highly effective air cooling system keeps the diode cold.
- A compatible mounting system allows hooking the laser to any chassis.
- A tuned and labeled lens to adjust the laser focus.
- An advanced Endurance MO1 PCB allows feeding the laser from an external power supply.
- An additional TTL wire enables to adjustment the power of the laser.
- The lightweight of the laser module reduces the momentum of inertia.
All Endurance lasers have similar parameters but different power output
Key features for Endurance lasers are:
Operating Voltage: 9-16V (sted – down “buck” DC/DC converters available upon request)
Operating Current: 2 – 14A
Cooling: active airflow (some units equipped with TEC cooling)
Mount: compatible with most 3D printers and CNC mills
Weight: 100-700 grams (~ 1/4 – 1.5 pounds)
Wavelength: 445 nm+-2nm (blue)
TTL: yes
Total lifetime: 10 000 hours.
Continuous operation time: 48-72 hours.
Focal range with 3 element lens: 2-10 cm (1-4”).
Focal range with G2 lens: 5-30 mm (0.2-1.25”)
Endurance laser production
Endurance has several steps while laser production:
- We purchase and test all components before starting an assembling process.
- We do metalwork: cut aluminum drill necessary holes in an aluminum housing, drill holes in a heatsink.
- We make our own laser driver.
- We make assembling: laser driver is inserted into a metal housing, laser diode inserted into a heatsink is mounted to the housing, screw fans.
- Final tests: we do 2-3 hours test of a final unit (measure temperature, measure power consumption, laser beam quality, power stability).
The difference between Chinese analogs
Unlike Endurance most Chinese diode lasers analogs with output 2 (2000 mw), 3 (3000 mw), 5 (5000 mw), 5.5 (5500 mw), 8 (8000 mw), 10 (10000 mw), 12 (12000 mw), 15 (15000 mw) watt output are not rated properly and in fact, do not have that power output.
Another issue is that most Chinese lasers do not work continuously and can operate only 5-15 minutes maximum and then require idle time.
Unlike Endurance, most Chinese companies do not provide customer support about how to connect, how to mount, etc.
Endurance lasers is a perfect tool for hobby and for business unlike Chinese fake lasers
From eager hobbyist to failed entrepreneur: Living in the world of Chinese Knockoffs
Personal experience with 8 watt laser (by Graham Ham)
Abilities of Endurance lasers
Endurance lasers can cut up to 8-10 mm of wood/plywood and dark acrylic.
Powerful Endurance lasers with 8W, 8.5W+ and 10W power output can engrave on anodized aluminum, copper, brass, stone, ceramics, and even on stainless steel.
All you need to know about Endurance tests of all incoming laser diodes. We test them carefully before we use them in our laser production.
Testing NUBM44 / 47 NICHIA Laser Diodes. Measuring Voltage, Current, Optical Power.
Endurance lasers power consumption
Measuring of voltage, current, and wattage
Everything you need to know about the laser
High-quality standard
Multi-level testing system.
Industrial components.
Ultra reliable
The guaranteed duration of the continuous operation ~48-72 hours.
True continuous power output
Our products have the rated power output as advertised – unlike Chinese analogues.
TTL mode
Can be turned on and off with 3.5-24V.
Variable power output.
Plug and play
Universal and compatible mount.
Compatible with most 3D printers and CNC machines.
Friendly return policy
Do not like the laser?
Simply return within 30 days and get a full refund.
Real-time advice
We assist and give advice by Phone / Email / Facebook messenger / Telegram / Whatsapp / Viber.
Professional support
We help to install and tune the laser. We offer qualified after-sales support.
Everything you need
We ship everything you need in one parcel to get started.
Immediate delivery
We ship all units within 4-24 hours. DHL express delivery allows you to get the package in 3-5 days.
Lifetime warranty
All our lasers are tested and could work up to 10000 hours.
Upgrade option
Do you have an old model? Upgrade your unit with more powerful one.
Our customers installed and run our lasers on the following machines:
Prusa mk3s, Monoprice maker select v2, x-сarve 1000×1000, Creality 3D cr-10S cr-10, TAZ5, CNC Shark 4HD, Robo3DR1+, Ender-3, Ender-2, Snapmaker, Tronxy x5s, Anycubic Photon, Solidoodle 2, Wanhao 4S, A large CNC machine controlled using Mach3 and an Ethernet Smooth Stepper, Ultimaker 2, CNCC Laseraxe, Monoprice maker select v2, Eleksmaker a3’s, Openbuilds Ox, Acro for laser, Tinyg controller for CNC and GRBL for laser.
